AlN-TL50
AlN-TL50
Aluminum nitride large particle filler powder is produced by self developed aluminum nitride powder.After spraying,granulation and sintering,it is screened and packed. The products are widely used in TIM(thermal interface material).
| Specifications | AlN-TL30 | AlN-TL50 | AlN-TL80 | AlN-TL100 | AlN-TL120 |
| D50/um | 35(±5) | 50(±5) | 80(±5) | 100(±5) | 120(±5) |
| Appearance | White | ||||
| Spherical | ＞95% | ＞95% | ＞95% | ＞95% | ＞95% |
| g·cm-3(Apparent density) | 1.5～1.6 | 1.6～1.7 | 1.65～1.75 | 1.65～1.75 | 1.65～1.75 |
| g·cm-3(Tap density) | 1.8～1.9 | 1.85～2.05 | 1.95～2.1 | 1.95～2.1 | 1.95～2.1 |
| 0/wt% | ＜2 | ＜2 | ＜2 | ＜2 | ＜2 |
| AIN/wt% | ＞96 | ＞96 | ＞96 | ＞96 | ＞96 |
