ALN-TL30
ALN-TL30
Aluminum nitride large particle filler powder is produced by self developed aluminum nitride powder.After spraying,granulation and sintering,it is screened and packed. The products are widely used in TIM(thermal interface material).
advantages:
1. Good fluidity, formability and chemical uniformity.
2. It can meet the requirements of dry pressing, semi-dry pressing, cold isostatic pressing and other processes.
| Specifications | AlN-TL30 | AlN-TL50 | AlN-TL80 | AlN-TL100 | AlN-TL120 |
| D50/um | 35(±5) | 50(±5) | 80(±5) | 100(±5) | 120(±5) |
| Appearance | White | ||||
| Spherical | ＞95% | ＞95% | ＞95% | ＞95% | ＞95% |
| g·cm-3(Apparent density) | 1.5～1.6 | 1.6～1.7 | 1.65～1.75 | 1.65～1.75 | 1.65～1.75 |
| g·cm-3(Tap density) | 1.8～1.9 | 1.85～2.05 | 1.95～2.1 | 1.95～2.1 | 1.95～2.1 |
| 0/wt% | ＜2 | ＜2 | ＜2 | ＜2 | ＜2 |
| AIN/wt% | ＞96 | ＞96 | ＞96 | ＞96 | ＞96 |
